EURO PLY (B.W.P. & M.R.GRADE)
EURO PLY is made from HARDWOOD and bonded with phenol Formaldehyde (PF) resin for BWP grade & with MELAMINE UREA FORMALDEHYDE (MUF) resin for M.R. grade. It is specially treated to repel termites and wood insects. It is made using high quality Gurjan face veneers of uniform thickness and chemically treated to make it warp free and dimensionally accurate.
Technical Details Conforming To Is: 710 Euro Ply B.W.P & Is:303 Mr Plywood
| Sr. No. | Prescribed Value | BWP IS:710 | MR GRADE IS:303 | ||
| Required Values | Observed Value | Required Value | Observed Value | ||
| 1 | Squarness (%) | <0.20% | 0.10 | <0.20% | 0.12 |
| 2 | Edge Straightness (%) | <0.20% | 0.15 | <0.20% | 0.17 |
| 3 | Moisture Content (%) | 5-15% | 8% | 5-15% | 7% |
| 4 | Adhesion of Plies | Min. Pass Standard | Excellent | Min. Pass Standard | Excellent |
| 5 | Water Resistance Test | 72 Hours Boiling | Satisfactory | 3 Hours Socking 60+20°c |
Satisfactory |
| 6 | Static Bending Strength
i) Along the grain direction ii) Across the grain direction |
Avg. – 7500 N/mm2 Avg. – 50 N/mm2 |
8100 58 |
Avg. – 4000 N/mm2 Avg. – 30 N/mm2 |
5240 48 |
| Avg. – 4000 N/mm,2 Avg. – 30 N/mm2 |
4100 35 |
Avg. – 2000 N/mm2 Avg. – 15 N/mm2 |
4100 34 |
||
*Conditions Applied as Per Warranty Certificate
 |
 |
 |
