EURO PLATINUM (B.W.P. & M.R.GRADE)
EURO PLATINUM PLY is made from GURJAN & Hardwood bonded with Phenol Formaldehyde (PF) resin for BWP grade & bonded with Melamine Urea Formaldehyde (MUF) resin for M.R. Grade. It is specially treated to repel termites and wood insects. It is made using high quality Gurjan face veneers of uniform thickness and chemically treated to make it warp free and dimensionally accurate.
EURO Platinum Marine Grade plywood, manufactured by using hard wood & Gurjan is PF resin bonded under high temperature & pressure to keep the bonding intact even after 72 hours of boiling test. The assembly of core and panels is done in such a way that the product does not have any gap inside. Thus the plywood has strong screw holding capability which makes it most suitable for any kind of woodwork
Technical Details Conforming To Is: 710 Euro Bwp Platinum Plywood & Is: 303 Mr Grade Plywood
| Sr. No. | Prescribed Value | BWP IS:710 | MR GRADE IS:303 | ||
| Required Values | Observed Value | Required Value | Observed Value | ||
| 1 | Squarness (%) | <0.20% | 0.10 | 0.20% | 0.12 |
| 2 | Edge Straightness (%) | <0.20% | 0.15 | <0.20% | 0.17 |
| 3 | Moisture Content (%) | 5-15% | 8% | 5-15% | 7% |
| 4 | Adhesion of Plies | Min. Pass Standard | Excellent | Min. Pass Standard | Excellent |
| 5 | Water Resistance Test | 72 Hours Boiling | Satisfactory | 3 Hours Socking at 60+20°c | Satisfactory |
| 6 | Static Bending Strength i) Along the grain direction Modulus of Elasticity Modulus of Rupture ii) Across the grain direction Modulus of Elasticity Modulus of Rupture |
||||
| Avg. – 7500 N/mm2 Avg. – 50 N/mm2 |
8150 54 |
Avg. – 4000 N/mm2 Avg. – 30 N/mm2 |
5240 48 |
||
| Avg. – 4000 N/mm,2 Avg. – 30 N/mm2 |
4200 36 |
Avg. – 2000 N/mm2 Avg. – 15 N/mm2 |
4100 34 |
||
*Conditions Applied as Per Warranty Certificate
 |
 |
 |
