EURO ELITE PLY is premium grade genuine marine grade plywood. It is manufactured with single wood veneer that is GURJAN wood and we guarantee for it. EURO ELITE PLY is manufactured as per the specifications of Marine Grade plywood and it confirms the IS: 710. Treated log of GURJAN wood are peeled with hydraulic peeling machine and then conditioned GURJAN veneers are bonded in HOT PRESS with high solid content and water proof Phenol Formaldehyde (PF) resins.

EURO ELITE PLY is a specially made to withstand rigorous condition of climatic changes, humidity level and other weather elements. Made from GURJAN and bonded with high quality Phenol Formaldehyde (PF) resin, EURO ELITE PLY is well protected from fungi, termites and its bonding is intact even after 72 hours of boiling and vacuum steam pressure test.

Technical Details Conforming To Is: 710 Marine Plywood

Sr. No. Prescribed Value Values for Conformity Observed Value
1 MOISTURE CONTENT 5-15% 8%
2 GLUE ADHESION IN DRY STATE
a) Glue Shear Strength
b) Adhesion of plies

Min. Av. 1350 N
Min. Pass Standard

1660 N
Excellent

3 WATER RESISTANCE TEST
a) A 120 kpc of vacuum and 220 kpa of steam Pressure
b) Glue Shear Strength in wet state
c) Adhesion of Plies

There shall be no Delamination
Min. Av. 1000 N
Min. Pass Standard

No Delamination
1320 N
Excellent

4 TENSILE STRENGTH
a) Along the face grain
b) Across the face grain
c) Sum of both direction

Min. 42.00 N/mm2
Min. 25.00 N/mm2
Min. 84.50 N/mm2

Min. 55.80 N/mm2
Min. 36.25 N/mm2
Min. 92.05 N/mm2

5 STATIC BENDING STRENGTH

a) Modulus of elasticity (MOE)

(i)Along the face grain
(ii)Across the face grain

b) Modulus of rupture (MOR)

(i) Along the face grain
(ii)Across the face grain

Min. 7500 N/mm2
Min. 4000 N/mm2

Min. 50 N/mm2
Min. 30 N/mm2


8960 N/mm2
5680 N/mm2

65.85 N/mm2
38.70 N/mm2

6 WET BENDING STRENGTH

a) Modulus of elasticity (MOE)

(i)Along the face grain
(ii)Across the face grain

b) Modulus of rupture (MOR)

(i) Along the face grain
(ii)Across the face grain

Min. 3750 N/mm2
Min. 2000 N/mm2


Min. 25 N/mm2
Min. 15 N/mm2

5160 N/mm2
3215 N/mm2


35.70 N/mm2
25.10 N/mm2

7 MYCOLOGICAL TEST There shall be no ply separation at the edge No ply separation

*Conditions Applied as Per Warranty Certificate
